Test tone with multi-fiber ID

What it does

MultiFiber ID provides simple and advanced test tone features on light sources, power meters and loss test sets.

  • It provides the usual 270 Hz, I KHz and 2 KHz tone functions of most test instruments
  • A light source can be set to any one of 12 extra test ID tones. So multiples sources can be set up at one time, all with different ID.
  • A Power meter recognizes and displays the numbered test tone, 1 - 12.
  • A Kingfisher power meter not equipped with MultiFiber ID still shows the test tone frequency anyway, so still usable.

Faster fault finding, continuity & polarity testing

  • Hook up to 12 light sources to 12 fibers at one time, each set to a different ID, to do rapid and easy continuity / polarity testing, greatly improving both productivity and confidence.
  • Simple and reliable to use, the meter automatically detects and displays 1 -12 tone numbers.
  • Ideally suited for 12 fiber ribbons / MPO connectors.
  • Can extend to 16 fibers (for MPO-16 / 32 connectors) by using the 2 KHz, 1 KHz, 270 Hz tones + no tone.

Multi-Fiber ID Instruments


KI 9600A Pocket Power Meter

  • Simple shirt-pocket size power meter
  • Options for all networks & users
  • Low-skill TamperLock mode
  • Ideal for transmission installers

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

KI 2600 Handheld Power Meter

  • Productivity power meter
  • Options for all networks & users
  • Ideal for cable installers
  • Powerful reporting capability
  • Optional VFL

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

KI 6102 GPON / PON Power Meter

  • Economical in-line meter for PON test
  • Simple and reliable operation
  • 1310 / 1490 / 1550 nm, two ports
  • 100 test memory with PC software
KI 9800A Pocket Fiber Source

  • Economical shirt-pocket size source
  • Options for SM, MM, POF etc
  • Low-skill TamperLock mode
  • MM is EF compliant
  • Eye safe high power VFL 5 mW
KI 6358 Pen Visual Fault Finder

  • Pen-sized universal VFL 1mW
  • Eye safe class 1 laser
  • LC / 1.25 mm universal adapter option
KI 2800 Handheld Source

  • Versatile productivity source
  • Options for SM, MM, POF etc
  • SM + MM quad up to 6 λ
  • Unique VisiTester VFL

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

KI 2400 Handheld Source with Zero Warm-up

  • Unique Zero Warm-up, optically stabilized source
  • Ultimate stability over temperature & ORL
  • Up to 6 SM λ
  • eLED option for precise loss & CD testing

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

KI 6610 FiberSafe Microscope

  • Microscope for inspection of SM, MM, MPO and POF networks
  • Best quality, image & eye safety
  • Wide range of interchangeable adaptors
  • Many helpful features



KI 6680 Fiber Inspection Probe

  • Scope to check mated & unmated connectors SM, MM, MPO
  • Software for Windows, Apple or Android devices
  • Wifi or USB connection
  • Easy operation



KI 7340 Handheld Two-Way Loss Test Set with ORL & Zero Warm-Up

  • Fastest & most accurate certifier
  • Bi-directional Loss & ORL on one fiber
  • Zero warm up time sources
  • Pass / Fail display

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

KI 7740 Handheld Two-Way Loss Test Set

  • Fastest fiber optic certifier
  • Bi-directional loss on one fiber
  • Pass / Fail display

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

KI 2700 Handheld Loss Test Set

  • Versatile Loss Test Set
  • VFL-VisiTester option
  • SM, MM & Quad versions
  • MPO CS POF versions

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

KI 2300 Handheld Loss Test Set with Zero Warm-Up

  • Highest accuracy OLTS
  • Zero warm-up time sources
  • Singlemode fiber only

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

KI 6170 Clip-on fiber identifier

  • Clip-on to check for traffic or test tones
  • Low false detection rate
  • Optical Power display
  • Requires a light source with tone facility
KI 7010 Series Variable Optical Attenuator

  • SM, MM & POF versions
  • Best optical specifications
  • Easy to use, rugged & reliable
  • Remote control vis RS232

ISO17025 traceable ILAC / NATA / ISO17025 Traceable Calibration

Hybrid Adaptor Series

  • Sources, attenuators, OLTS
  • Most power meters except XL series
  • G2 connector
  • Useful to make test adapter leads
XL Series Power Meter Adaptor Series

  • Large area XL series power meters
  • Legacy KI6000 power meters
  • Also fits other instruments
KI66xx Microscope Adaptor Series

  • KI661x FiberSafe Optical Microscope
Miscellaneous Accessories

Various accessories and kit components for Kingfisher testers.

MPO Patch Cords & Test Leads

Test Grade MPO Patch Leads to improve your test accuracy

Fiber Test Leads

Test Grade SC and LC Patch Leads to improve your test accuracy

Single mode, multimode, PC, APC

Cold Clamp (buried cable fault locator)

  • Use liquid nitrogen to induce a non-destructive optical marker
  • Use with OTDR to localize physical fault within 1m
  • Significantly improve real-world response & labor time
  • Works on live systems
KI-UBENCH

POF air-gap collimator assembly useful to place bulk optics devices, sensors or samples into plastic optical fiber light path.

G2 Panel Mount Connector Series

  • Universal Optical Connector for OEM, test & production
  • For connectors with 2.5 & 1.25 mm ferrule, SMA, POF and others
